GE160ES Spherical Plain Bearing 160mm ID Carbon Steel Rod End

MOQ:	1 pcs
prezzo:	$120 / pcs
Imballaggio standard:	Packed in carton firstly,and then reinforced with wooden case for outer packing
Periodo di consegna:	3 working days after received your payment
Metodo di pagamento:	T/T or western Union or PayPal
Capacità di approvvigionamento:	3,000pcs per month

Dettagli Informazioni

Descrizione del prodotto

Informazioni dettagliate

Place of Origin

China

Marca

Certificazione

ISO9001:2008

Model Number

GE160ES-2RS

Product Name:

GE160ES

Precision Rating:

ABEC1 ABEC3 ABEC5

Type:

Rod end

Material of the ball:

Carbon Steel

Inner diameter:

160mm

Outside diameter:

230mm

Thickness:

Evidenziare:

160mm spherical plain bearing

carbon steel rod end bearing

GE160ES spherical bearing with warranty

Descrizione del prodotto

High Quality GE160-DO GE 160 ES-2RS GE 160 TA-2RS GE160ES Shock Absorber GE 160 E GE160E Radial Spherical Plain Bearing

Product Specifications

Product Name	GE160ES
Precision Rating	ABEC1 ABEC3 ABEC5
Type	Rod end
Material of the ball	Carbon Steel
Inner diameter	160mm
Outside diameter	230mm
Thickness	90mm

Product Description

Rod end joint bearing GE140ES. GE..ES is a Plain Spherical Ball Bearing which is capable of withstanding both large radial loads as well as bi-directional axial loads at the same time. This GE..ES bearing incorporates an inner and outer ring with a spherical sliding surface and a single piece race type construction providing excellent ball-to-race conformity. This GE..ES can be re-lubricated through an annular groove in the outer race with two interconnecting holes positioned at 180 degrees and is ideal for applications using high shock loads and high alternating loads.

GE Series Product Line

GE ... ES Series	GE ... ES-2RS	GEH ... ES-2RS
GE 4 ES	GE 70 ES	GE 15 ES-2RS	GE 140 ES-2RS	GEH 20 ES-2RS
GE 5 ES	GE 80 ES	GE 17 ES-2RS	GE 160 ES-2RS	GEH 25 ES-2RS
GE 6 ES	GE 90 ES	GE 20 ES-2RS	GE 180 ES-2RS	GEH 30 ES-2RS
GE 8 ES	GE 100 ES	GE 25 ES-2RS	GE 200 ES-2RS	GEH 35 ES-2RS
GE 10 ES	GE 110 ES	GE 30 ES-2RS	GE 220 ES-2RS	GEH 40 ES-2RS
GE 12 ES	GE 120 ES	GE 35 ES-2RS	GE 240 ES-2RS	GEH 45 ES-2RS
GE 15 ES	GE 140 ES	GE 40 ES-2RS	GE 260 ES-2RS	GEH 50 ES-2RS
GE 17 ES	GE 160 ES	GE 45 ES-2RS	GE 280 ES-2RS	GEH 60 ES-2RS
GE 20 ES	GE 180 ES	GE 50 ES-2RS	GE 300 ES-2RS	GEH 70 ES-2RS
GE 25 ES	GE 200 ES	GE 60 ES-2RS		GEH 80 ES-2RS
GE 30 ES	GE 220 ES	GE 70 ES-2RS		GEH 90 ES-2RS
GE 35 ES	GE 240 ES	GE 80 ES-2RS		GEH 100 ES-2RS
GE 40 ES	GE 260 ES	GE 90 ES-2RS		GEH 110 ES-2RS
GE 45 ES	GE 280 ES	GE 100 ES-2RS		GEH 120 ES-2RS
GE 50 ES	GE 300 ES	GE 110 ES-2RS
GE 60 ES		GE 120 ES-2RS

Frequently Asked Questions

How do I ensure proper lubrication for Spherical Plain Bearings in high-load, low-speed applications?

Proper lubrication is critical for Spherical Plain Bearings, especially in demanding environments with heavy loads and minimal rotation. For these conditions, it's recommended to use a heavy-duty grease or oil that can withstand high pressures and resist washout. Regular re-lubrication intervals should be established based on the specific application's load, speed, and environmental factors. Consider using seals or protective caps compatible with your Spherical Plain Bearing design to prevent contamination and retain lubrication, thereby extending bearing life and performance.

What material options are available for Spherical Plain Bearings to handle corrosive environments?

To cope with corrosive environments, Spherical Plain Bearings are commonly offered in various corrosion-resistant materials. Standard options include stainless steel, which provides good general corrosion resistance, or for more severe conditions, bearings made from special alloys like duplex stainless steel or those with PTFE (polytetrafluoroethylene) liner materials can be utilized. These materials, particularly PTFE-based ones, offer low friction and excellent chemical resistance, making them ideal for marine or chemical processing industries where corrosion is a major concern.

Tag:

cuscinetto scorrevole sferico,

cuscinetti metrici sferici,

cuscinetto sferico normale
